| 1 |
306-45-00012-1 |
Electronic motor (RZR 2102 control) -- 230V
|
230V |
|
1 |
PI |
|
0
|
| 2 |
687-306-0013-0 |
Gear motor (RZR 2052 control) -- 230V
|
230V |
|
1 |
PI |
|
0
|
| 1 |
306-45-00014-1 |
Electronic motor (RZR 2102 control) -- 115V
|
115V |
|
1 |
PI |
|
0
|
| 3 |
13-225-501-10-0 |
SP PCB Power supply/output (RZR 2052 control) -- 230V
|
230V |
|
1 |
PI |
|
0
|
| 4 |
13-225-501-09-0 |
SP PCB Interface/Filter adjusted (RZR 2052 control) -- 230V
|
230V |
|
1 |
PI |
|
0
|
| 4 |
13-116-501-09-0 |
SP PCB Interface/Filter adjusted (RZR 2052 control) -- 115V
|
115V |
|
1 |
PI |
|
0
|
| 5 |
13-001-501-02-0 |
SP PCB Display (RZR 2052 control)
|
|
|
1 |
PI |
|
0
|
| 6 |
14-002-015-69-1 |
Fuse TR5 T 2,0A/250V (VDE)
|
230V |
|
1 |
PI |
|
0
|
| 7 |
11-001-501-40-0 |
Cap with power supply (RZR 2051-2/2102) -- 230V
|
230V |
no longer available |
1 |
PI |
|
0
|
| 7 |
11-001-501-41-0 |
Cap with power supply (RZR 2051-2/2102) -- 115V
|
115V |
Index 2 |
1 |
PI |
|
0
|
| 8 |
11-001-200-95-0 |
Spare part kit: Front panel (RZR 2052)
|
no longer available |
RZR 2052 |
1 |
PI |
|
0
|
| 9 |
14-300-010-15-0 |
Spare part kit: 2-pole switch with cap
|
|
|
1 |
PI |
|
0
|
| 10 |
26-001-300-45-1 |
Spur gear Z=25/HTD=29
|
|
|
1 |
PI |
|
0
|
| 11 |
26-007-300-05-1 |
Toothed belt 129-3M-09
|
|
|
1 |
PI |
|
0
|
| 11 |
26-007-300-16-1 |
Toothed belt 180-3MGT3-9-610
|
|
|
1 |
PI |
|
0
|
| 12 |
11-003-015-66-0 |
Intermediate piece belt cpl.
|
|
|
1 |
PI |
|
0
|
| 13 |
11-003-015-67-0 |
Output shaft piston drive (RZR 2052)
|
|
no longer available |
1 |
PI |
|
0
|
| 14 |
23-09-01-01-45-0 |
Rubber-metal buffer
|
|
|
1 |
PI |
|
0
|
| 15 |
11-013-504-07-1 |
Rotary knob
|
|
|
1 |
PI |
|
0
|
|
509-02000-00-0 |
Chuck 10 mm (RZR 2xxx)
|
|
|
1 |
PI |
|
0
|
|
22-02-14-01-08-0 |
Support rod 13x160 mm (RZR 20xx/21xx)
|
|
|
1 |
PI |
|
0
|
|
20-004-044-28-0 |
Cover plate (RZR 2052 / 2102)
|
|
|
1 |
PI |
|
0
|
|
20-004-044-26-0 |
Left side section painted (RZR 20xx / 21xx)
|
|
|
1 |
PI |
|
0
|
|
23-08-06-01-35-0 |
Rubber ring (O-ring) (RZR 2050/2051/2100/2101/2102)
|
|
|
1 |
PI |
|
0
|
|
11-001-200-79-0 |
Rear housing (RZR 2052)
|
|
|
1 |
PI |
|
0
|
