Distimatic Industrial Platinum Package
Hei-VOLUME Distimatic Industrial Packages
Distimatic Industrial Platinum 4 Package
P/N: 518-14152-00
The package includes:
- Hei-VAP Industrial large-scale rotary evaporators without base cart: With 20 l rotary flask and automatic bath refill for unattended and continuous use.
- Hei-VOLUME Distimatic Industrial automatic module: For automated filling of the rotary flask and condensate drainage through a chemistry diaphragm pump
- Glassware to match your requirements - with double condenser, especially for initially foaming media
Also included:
- Glassware A2 (without receiving flask and distributor): Evaporation and clean separation of foaming media with maximum efficiency. Suitable for the most common solvents (including acetone, hexane, ethanol and water).
- An expansion vessel as a foam brake, as well as a condenser with descending and a condenser with ascending condensation (condensation surface: 1.2 m²).
Picture similar
Variants
Distimatic Industrial Platinum 5 Package
P/N: 518-13152-00
The package includes:
- Hei-VAP Industrial large-scale rotary evaporators without base cart: With 20 l rotary flask and automatic bath refill for unattended and continuous use.
- Hei-VOLUME Distimatic Industrial automatic module: For automated filling of the rotary flask and condensate drainage through a chemistry diaphragm pump
- Glassware to match your requirements - - with single condenser, especially for highly foaming media during processing
Also included:
- Glassware A (without receiving flask and distributor): Evaporation and clean separation of highly foaming media during the process.
- An expansion vessel as a foam brake and a condenser with descending condensation (condensation surface: 0.6 m²).
Picture similar
Variants
Distimatic Industrial Platinum 6 Package
P/N: 518-11152-00
The package includes:
- Hei-VAP Industrial large-scale rotary evaporators without base cart: With 20 l rotary flask and automatic bath refill for unattended and continuous use.
- Hei-VOLUME Distimatic Industrial automatic module: For automated filling of the rotary flask and condensate drainage through a chemistry diaphragm pump
- Glassware to match your requirements - with single condenser, especially for high-boiling solvents
Also included:
- Glassware R (without receiving flask and distributor): For efficient evaporation of high-boiling solvents such as xylene, DMF or DMSO.
- With shut-off valve for operating the rotary evaporator as a reflux reactor. A condenser with ascending condensation (condensation surface: 0.6 m²).
Picture similar
Variants
Distimatic Industrial Platinum 8 Package
P/N: 518-14152-20
The package includes:
- Hei-VAP Industrial large-scale rotary evaporators without base cart: With 20 l rotary flask and automatic bath refill for unattended and continuous use.
- Hei-VOLUME Distimatic Industrial automatic module: For automated filling of the rotary flask and condensate drainage through a chemistry diaphragm pump
- Glassware to match your requirements - with double condenser for maximum distillation performance of the most common solvents
Also included:
- Glassware A1 (without receiving flask and distributor): Evaporation and clean separation with maximum efficiency. Suitable for the most common solvents (including acetone, hexane, ethanol and water)
- An riser tube for optimal separation, as well as a condenser with descending and a condenser with ascending condensation (condensation surface: 1.2 m²).
Picture similar
Variants
Distimatic Industrial Platinum Package
The package includes:
- Hei-VAP Industrial large-scale rotary evaporators without base cart: With 20 l rotary flask and automatic bath refill for unattended and continuous use.
- Hei-VOLUME Distimatic Industrial automatic module: For automated filling of the rotary flask and condensate drainage through a chemistry diaphragm pump
- Glassware to match your requirements - more information when selecting your package variant in the drop-down menu:
- Distimatic Industrial Platinum 4 Package (especially for initially foaming media)
- Distimatic Industrial Platinum 5 Package (especially for highly foaming media during processing)
- Distimatic Industrial Platinum 6 Package (especially for high-boiling solvents)
- Distimatic Industrial Platinum 8 Package (for the highest distillation performance of the most common solvents)
Picture similar
